BuildPro Welding Tables

From small tasks to large-scale projects, BuildPro has the perfect welding tables and fixturing tools to meet your needs. Engineered for precision, versatility, and durability, BuildPro products are trusted by professionals across industries. Whether you're working in a compact workshop or managing complex fabrication jobs, BuildPro's modular design and expansive accessory options ensure you get the job done right—every time.

Discover More About BuilPro

Alpha28 Tables

Our largest and most robust tables to date. Featuring 5 distinct tabletop sizes and equipped with 28 mm boreholes, this series offers an exceptional heavy-duty surface, perfectly catering to all your welding requirements.

Shop Alpha 28

Alpha 5/8 Tables

The Alpha 5/8 series is a versatile, 5-sided medium-duty table with 5/8" boreholes, offering five size options and greater flexibility than single-sided tables.

Mobile Working Stations

A versatile line designed for maximum productivity and flexibility, fully compatible with all 5/8 tooling.

MAX Tables

The OG of modular welding tables: BuildPro MAX, available in 11 sizes with slotted or slotless tops and two finish options for maximum flexibility.

16 mm Tooling

Compatible with all welding tables with 16 mm boreholes from any table manufacturer

System Comparison

	Alpha 28 Tables	Alpha 5/8 Tables	MAX Tables	Rhino Carts	FixturePoint Tables (Legacy)
System	Metric	Imperial	Imperial	Imperial	Metric
Table Hole Dia.	28 mm (1.1")	5/8"	5/8"	5/8"	16 mm (0.63")
Hole Spacing	100 mm (3.9")	2.000"	2.000"	2.000"	50 mm (2")
Table Flatness	±0.125 mm per 600 x 600 mm (±0.005 per 24" x 24")	±0.005 per 24" x 24"	±0.005 per 24" x 24"	±0.015" per 24" x 24"	0.7 mm per 1,000 mm (0.028" per 40")
Top Plate Thickness	25 ±0.06 mm (1" ±0.002)	0.47" ±0.004	0.630" ±0.004	0.630" ±0.004	4 ±0.3 mm (0.16" ±0.01)
Tabletop Side Height	200 mm (7.9")	6"	6.25"	4.3"	109 mm (4.3")
Finish	Nitrided	Nitrided	Nitrided / Standard	Nitrided	Standard
