Welding Tables, Workstations & Fixturing Kits – Strong Hand Tools

System Comparison

	Alpha 28 Tables	Alpha 5/8 Tables	MAX Tables	Rhino Cart	FixturePoint Tables
System	Metric	Imperial	Imperial	Imperial	Metric
Table Hole Dia.	28 mm (1.1")	5/8"	5/8"	5/8"	16 mm (0.63")
Hole Spacing	100 mm (3.9")	2.000"	2.000"	2.000"	50 mm (2")
Table Flatness	±0.125 mm per 600 x 600 mm (±0.005 per 24" x 24")	±0.005 per 24" x 24"	±0.005 per 24" x 24"	±0.015" per 24" x 24"	0.7 mm per 1,000 mm (0.028" per 40")
Top Plate Thickness	25 ±0.06 mm (1" ±0.002)	0.47" ±0.004	0.630" ±0.004	0.630" ±0.004	4 ±0.3 mm (0.16" ±0.01)
Tabletop Side Height	200 mm (7.9")	6"	6.25"	4.3"	109 mm (4.3")
Finish	Nitrided	Nitrided	Nitrided / Standard	Nitrided	Standard
