California Prop 65 - This product may contain chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. For more info: www.P65Warnings.ca.gov
All BuildPro® Tables are constructed from 5/8" thick steel plate, with Ø5/8" CNC machined and holes chamfered in a 2" grid pattern.
All Slotted tables have 1.7" slots between plates.
Actual Table Surface Dimension: 78" x 48"
Tabletop Side Height: 6-1/4"
* All load capacities are calculated based on static load.
* Optional Leg Brace Assembly TMLBR78 is suggested.
U.S. PAT. 8065967
| Part No. (Standard Finish) | Part No. (Nitrided Finish) | Use with Leg | Table Surface Height (in) | Gross Weight (lb) |
|---|---|---|---|---|
| TMA57846 | TMQA57846 | TML3130 | 36-1/2 | 906 |
| TMB57846 | TMQB57846 | TML2530 | 30-1/2 | 894 |
| Part No. (Standard Finish) | Part No. (Nitrided Finish) | Use with Leg | Table Surface Height (in) | Gross Weight (lb) |
|---|---|---|---|---|
| TMR57846 | TMQR57846 | TMLR30 | 28-1/2 ~ 38-1/2 | 927 |
| Part No. (Standard Finish) | Part No. (Nitrided Finish) | Use with Leg | Table Surface Height (in) | Gross Weight (lb) |
|---|---|---|---|---|
| TMRC57846 | TMQRC57846 | TMLC30 | 33-1/4 ~ 43-1/4 | 961 |
If you need some documents but not able to find them here, please fill out the form below. Our engineering team will get back to you shortly.
Patented Bushing design allows you to remove, re-position, re-align, and reverse the table plates!
6-1/4″ for both MAX and MAX Slotted tables
Table flatness: ±0.005 per 24″ x 24″
Hole spacing: 2.000″ ±0.001
Hole diameter: 0.625″ +.002/-.000
Plate thickness: 0.630″ ±0.004
Slot: 1.7″
Choose from standard finish (medium carbon steel) or Nitrided (heat-treating) finish.
Adam S (Hazel Park, MI)
Austin N (Pro-Grow Supply)
Jason C (Industrial Flow Solutions)
Mike T
I used these same tables that were old at my old job but they were so accurate, I landed a large job that required high quality ballistic doors. Took the opportunity to buy two! And I figure they will last me for life!
I can now develop more complicated projects for my metalworking high school students to produce. Great product! I love the replaceable surface panels. As my students learn metalworking and fabrication skills the quality of the table has been great even through the learning curve and a few oops moments with angle grinders.
Absolutely the best welding table I love the welding table held out so much
Our classes will benefit from the table. Fabrication can be a bigger part of the curriculum! We can insert pipe and heat and bend with oxyacetylene now!
Absolutely the best
| Description |
| Product variants |
| Price |
| All BuildPro® Tables are constructed from 5/8" thick steel plate, with Ø5/8" CNC machined and holes chamfered in a 2" grid pattern. All Slotted tables have 1.7" slots between plates. Actual Table Surface Dimension: 78" x 48" * All load capacities are calculated based on static load. * Optional Leg Brace Assembly TMLBR78 is suggested. U.S. PAT. 8065967 |
Regular price
From $4,930.00 USD
Sale price
From $4,930.00 USD
Regular price
|
Hurry up, only 8 items left in stock.
All BuildPro® Tables are constructed from 5/8" thick steel plate, with Ø5/8" CNC machined and holes chamfered in a 2" grid pattern.
All Slotted tables have 1.7" slots between plates.
Actual Table Surface Dimension: 78" x 48"
Tabletop Side Height: 6-1/4"
* All load capacities are calculated based on static load.
* Optional Leg Brace Assembly TMLBR78 is suggested.
U.S. PAT. 8065967
